Max. Allowable Terminating
VSWR 2.00:1
VSWR Range 1.00 to 2.00 (40.0 to 9.5 dB Return Loss)
Calibration Technique Frequency-specific calibration factors stored in
nonvolatile memory in each sensor. Sensor
output corrected for frequency and tempera-
ture within specified ranges.
Cal. Cycle, Nominal 1 year
Connectors Customer specified from QC list, appropriate
for frequency and power.
Sampling Rate, Nominal 2 readings/second
Operating Power Supplied by power meter via sensor cable
Humidity, Max. 95% (Non-condensing)
Altitude, Max. 10,000 feet (3,000 m)
CE CE Compliant. Refer to Declaration of Confor-
mity for specific standards.
Temperature Range
Operating
Storage
0 to 50 °C (32 to 122 °F)
–20 to +70 °C (–4 to +158 °F)
Dimensions 5.2”L x 2.5”W x 3.25”H
(137 x 64 x 83 mm)
Weight, Nominal 1 lb. 13 oz. (0.8 kg)
* For rated accuracy, no more than 1% AM; Harmonics –50 dBc or
less
Derate accuracy by 3.0% (1
σ ) below 15 °C and above 35 °C
