BDS TM System
PARAMETER SPECIFICATIONS
Frequency Range 1 MHz - 500 MHz (Sensor Dependent)
Frequency Resolution 100 Hz
Frequency Accuracy ± 1 kHz
Harmonics 15 maximum, up to 500 MHz (Sensor Dependent)
Number of fundamentals (F0) Maximum of 5 simultaneously
Digital > Voltage, current, phase, frequency,
impedance, power at frequencies selected
by user
Analog 5 Outputs, 0-10Vdc, 1000Ω-source
Update Rates 60 Hz typical for 1 fundamental (Note 1)
Network Protocol DeviceNet, Ethernet
RF Power, Max 10 kW or maximum power limit of RF connector
RF Connector Custom or QC
Receiver Operating +20 to +40 °C (68 to 104 °F)
Receiver Storage -20 to +80 °C (-4 to +176 °F)
Cable Operating 0 to +100 °C (32 to 212 °F)
Cable Storage -20 to +100 °C (-4 to 212 °F)
Sensor Operating/Storage Refer to Sensor Specification
Humidity, Max 85% Non-condensing
Air Pressure, min 745 mbar (equivalent to 2,500 m / 8,200 ft.
max altitude)
Operating Power 11-24 Vdc, 1.4-3A input to receiver
PARAMETER VOLTAGE CURRENT PHASE ANGLE
Measurement RF: 1 to 3000Vrms (Note 2) 0.1 to 100 Arms (Note 2) -180° to + 180°
Resolution IEEE 754 Single Precision Floating Point
Uncertainty 1-100 MHz (Note 3) for F
°
, ± 0.2 V or 2% of reading
whichever is greater for F
n
, ± 0.4 V or
4% of reading, whichever is greater
(95% confidence intreval)
for F
°
, ± 0.02 A or 2% of reading
whichever is greater for F
n
, ± 0.04 A
or 4% of reading, whichever is greater
(95% confidence intreval)
Absolute Angle:
for F
°
, ≥ 10 V, 1A:, ±1°
for F
°
, < 10 V, 1A:, ±4°
for F
n
,
≥ 10 V, 1A:, ±2°
for F
n
, < 10 V, 1A:, ±6°
(95% confidence intreval)
Uncertainty 1-500 MHz (Note 3) for F
°
, ± 0.3 V or 3% of reading
whichever is greater for F
n
, ± 0.6 V or
6% of reading, whichever is greater
(95% confidence intreval)
for F
°
, ± 0.03 A or 3% of reading
whichever is greater for F
n
, ± 0.06 A
or 6% of reading, whichever is greater
(95% confidence intreval)
Absolute Angle:
for F
°
, ≥ 10 V, 1A:, ±2°
for F
°
, < 10 V, 1A:, ±8°
for F
n
,
≥ 10 V, 1A:, ±4°
for F
n
, < 10 V, 1A:, ±12°
(95% confidence intreval)
Receiver Temperature
Derating - From 25 °C
± 0.05% / °C ± 0.05% / °C ± 0.1% / °C
30303 Aurora Rd. Solon, OH 44139 866.695.4569 www.bird-technologies.com
Note 1: Typical data rate for 1 fundamental, 15 harmonics, auto-ADC mode, and no averaging is 60 Hz. Typical data rate for 3 fundamentals, 45 harmonics,
auto-ADC mode, and no averaging is 24 Hz. Data rate can vary significantly depending on configuration, network traffic, and host performance.
Note 2: Maximum power is limited by the size of the sensor line section and connectors. See sensor specification document.
Note 3: At customer specified frequencies.
SYSTEM COMPONENTS
Receiver
7001B200-1 BDS Single Ch. Receiver w/DeviceNet
Calibrated Data Cable Options
7001A040-SS-2M BDS RF/Data Cable Set 2M straight
7001A040-SS-5M BDS RF/Data Cable Set 5M straight
Sensor Options*
7001A050-1 Sensor, QC Interface (Specify Connectors)
7001A050-1-DF-DM Sensor, BDS, DIN(f ) Input, DIN(m) Output
7001A050-1-NF-NF Sensor, BDS, N(f )-N(f )
7001A050-1-NM-NF Sensor, BDS, N(m)-N(f )
*Contact factory for a custom designed sensor.
