Bird 8890 Series Semiconductor Termaline Coaxial Load Resistor

2

Figure 1

Bird 8890 Series

Outline Drawing

MTG. HOLE

DETAIL

3/8”

(9 mm)

3/16”

(5 mm)

3/8”

(10 mm)

!

4.5”

(114 mm)

7.5”

(190 mm)

(4) MTG. HOLES

SEE DETAIL

21.5”

(546 mm)

17.25”

(437 mm)

3”

(75 mm)

DEPENDS ON

CONNECTOR

VENT PLUG

INTERLOCK

THERMOSWITCH

(OPTIONAL)
