Oil Dielectric
SC13 Series
Ultra Stable, Oil Dielectric RF Termination Loads
Load_Oil_SC13Seires-06072013
30303 Aurora Rd. Solon, OH 44139 866.695.4569 www.bird-technologies.com
ULTRA-STABLE SC13 LOADS
Model Frequency Range & VSWR Power Rating Dimensions Weight
8865SC13 DC to 28 MHz at 1.1 max.
VSWR less than 1.05:1 1 kW 19.5" x 7.5" x 13.2"
496mm x 184mm x 334mm 32 lbs.
14.5 kg
8890-300SC13 DC to 28 MHz at 1.1 max.
VSWR less than 1.05:1 2.5 kW 25.2" x 7" x 17.2"
638mm x 178mm x 437mm 59 lbs.
27 kg
8921SC13 DC to 28 MHz at 1.1 max.
VSWR less than 1.05:1 5 kW 32.8" x 9.5" x 26.9"
832mm x 241mm x 681mm 126 lbs.
57 kg
8931-115SC13 DC to 28 MHz at 1.1 max.
VSWR less than 1.05:1 10 kW 115 Volt 32.8" x 9.5" x 33.4"
832mm x 241mm x 847mm 142 lbs.
65 kg
8931-230SC13 DC to 28 MHz at 1.1 max.
VSWR less than 1.05:1 10 kW 230 Volt 32.8" x 9.5" x 33.4"
832mm x 241mm x 847mm 142 lbs.
65 kg
SPECIFICATIONS
Frequency Range dc – 28 MHz
Impedance 50 ohms
VSWR 1.1 max.
VSWR Stability < 0.1 dB, from 0 to 100% rated power
at stability frequency
Stability Frequency 13.56 MHz ± 10 kHz
Connector “QC” Type, Female LC normally supplied
Interlock Thermoswitch (Optional) Normally closed. Opens at 236 °C (457 °F)
Thermoswitch Rating 115 Vac
230 Vac 10A
5A
Temperature, Operating +5 to +40 °C (+41 to +104 °F)
Temperature, Storage – 40 to +45 °C (– 40 to +113 °F)
Altitude* 1520 m (5000 ft.)
Humidity 95% noncondensing max
Cooling method Oil dielectric and convection currents
Finish Black Epoxy Resin
