Digital Air Load
High-Power Forced Air Loads For Broadcast Applications
30303 Aurora Rd. Solon, OH 44139 866.695.4569 www.bird-technologies.com
SPECIFICATIONS
Impedance 50 ohm nominal
VSWR 1.05:1 typical, 1.10:1 maximum
Cooling Method Forced air-cooled
Peak to Average Power 13dB
Ambient Temperature -40°C to +45°C (-40°F to +113°F)
Interlock Contact Rating 10 A @ 120 VAC, 5A @ 250 VAC
Finish Blue Powder Coat
AC Power Required 115 V/230 V 50/60 Hz
MODEL POWER
RATING
FREQUENCY
RANGE
DIMENSIONS(LxWxH) WEIGHT CONNECTOR AC
POWER
DA10V1F15
DA10V1U15
DA10V1F30
DA10V1U30 10 kW
10 kW
10 kW
10 kW 0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF 23.5” x 23.5” x 59”
597 mm x 597 mm x 1499 mm 130 lbs
58.97 kg 1 5/8” Flanged
1 5/8” Unflanged
1 5/8” Flanged
1 5/8” Unflanged 115 VAC
115 VAC
230 VAC
230 VAC
DA10V3F15
DA10V3U15
DA10V3F30
DA10V3U30 10 kW
10 kW
10 kW
10 kW 0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF 23.5” x 23.5” x 59”
597 mm x 597 mm x 1499 mm 130 lbs
58.97 kg 3 1/8” Flanged
3 1/8” Unflanged
3 1/8” Flanged
3 1/8” Unflanged 115 VAC
115 VAC
230 VAC
230 VAC
DA25V3F15
DA25V3U15
DA25V3F30
DA25V3U30 25 kW
25 kW
25 kW
25 kW 0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF 27” x 27” x 61”
686 mm x 686 mm x 1549 mm 160 lbs
72.57 kg 3 1/8” Flanged
3 1/8” Unflanged
3 1/8” Flanged
3 1/8” Unflanged 115 VAC
115 VAC
230 VAC
230 VAC
DA25V4U15
DA25V4U30 25 kW
25 kW 0-240 MHz-AM, FM, VHF
0-240 MHz-AM, FM, VHF 27” x 27” x 61”
686 mm x 686 mm x 1549 mm 160 lbs
72.57 kg 4 1/2” Unflanged
4 1/2” Unflanged 115 VAC
230 VAC
DA5F15
DA5U15
DA5F30
DA5U30 5 kW
5 kW
5 kW
5 kW 470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF 17” x 17” x 64”
432 mm x 432 mm x 1608 mm 100 lbs
45.5 kg 3 1/8” Flanged
3 1/8” Unflanged
3 1/8” Flanged
3 1/8” Unflanged 115 VAC
115 VAC
230 VAC
230 VAC
DA10F15
DA10U15
DA10F30
DA10U30 10 kW
10 kW
10 kW
10 kW 470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF 19.5” x 19.5” x 68.5”
495 mm x 495 mm x 1740 mm 130 lbs
58.97 kg 3 1/8” Flanged
3 1/8” Unflanged
3 1/8” Flanged
3 1/8” Unflanged 115 VAC
115 VAC
230 VAC
230 VAC
DA15F15
DA15U15
DA15F30
DA15U30 15 kW
15 kW
15 kW
15 kW 470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF 25” x 25” x 76.5”
635 mm x 635 mm x 1943 mm 192 lbs
87.09 kg 3 1/8” Flanged
3 1/8” Unflanged
3 1/8” Flanged
3 1/8” Unflanged 115 VAC
115 VAC
230 VAC
230 VAC
DA25F15
DA25U15
DA25F30
DA25U30
DA25-4F15
DA25-4U30 25 kW
25 kW
25 kW
25 kW
25 kW
25 kW 470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF 27” x 27” x 76.5”
686 mm x 686 mm x 1943 mm 245 lbs
111.13 kg 4 1/16” Myat Flanged
4 1/16” Myat Unflanged
4 1/16” Myat Flanged
4 1/16” Myat Unflanged
4 1/2” IEC Flanged
4 1/2” IEC Unflanged 115 VAC
115 VAC
230 VAC
230 VAC
115 VAC
230 VAC
DA40-5U15
DA40-5U30
DA40F15
DA40F30
DA40U30 40 kW
40 kW
40 kW
40 kW
40 kW 470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF
470-890 MHz UHF 27.5” x 27.5” x 84”
701 mm x 701 mm x 2134 mm 310 lbs
140.6 kg 4 7/8” IEC Unflanged
4 7/8” IEC Unflanged
6 1/8” IEC Flanged
6 1/8” IEC Flanged
6 1/8” IEC Unflanged 115 VAC
230 VAC
115 VAC
230 VAC
230 VAC
