SPECIFICATIONS
Frequency Range SA-3600XT
SA-6000XT
25-3600 MHz
25-6000 MHz
Frequency Resolution SA-3600XT
SA-6000XT
25 kHz; 25-800 MHz,
50 kHz; 800-2500 MHz,
150 kHz; 2500-3600 MHz
25 kHz; 25-800 MHz,
50 kHz; 800-2500 MHz,
150 kHz; 2500-6000 MHz
Power Measurement SA-3600XT
SA-6000XT
Yes
Yes
Return Loss 0 to -60 dB
Test Port N-type female connector
Impedance 50 ohms
Speed 1 multi-frequency scan
(238 points)/2 seconds
1 multi-frequency scan
(475 points)/3.5 seconds
1 multi-frequency scan
(949 points)/6 seconds
Trace Resolution 238 (default), 475, or 949 per trace
Storage Capacity Thousands of setups and traces
Immunity to Interfering
Signals
Rejects on-frequency signals up
to +13 dBm
Maximum Input Signal +22 dBm
Data Transfer Sensor: USB 2.0 Type A
PC: USB 2.0 Type B
Internal Time Rechargeable lithium-Ion
batteries. 5-hour minimum
operating time. Auto shut-off
conserves battery life
External DC 9-15 VDC fused, <3 A
External AC 100 to 240 VAC @ 50-60 Hz;
AC/DC adapter required
Operating Temperature -10° to +50° C (+14° to +122° F)
Storage Temperature -40° to +80° C (-40° to +176° F)
Battery Charging
Temperature
0° to + 35° C (32° to 95° F)
Humidity 95% ± 5% max., (non-condensing)
Altitude Up to 15,000 feet (4572 m)
Dimensions 10.5” x 8.4” x 3.3” (265 x 212 x 83 mm)
Weight 5.5 lbs. (2,5 kg)
Upgradeable Yes, SA-3600XT maybe upgrade to
SA-6000XT
SiteAnalyzer_XTSeries-09232014
30303 Aurora Rd. Solon, OH 44139 866.695.4569 www.bird-technologies.com
Site Analyzer XT Series
SA-3600XT, SA-6000XT
STANDARD ACCESSORIES
AC Adapter (15 Vdc Output) 5B2229-1224G-1
Automobile Cigarette Lighter Adapter 5A2238-2
Soft Carrying Case 7002A850
USB Interface Cable 5A2653-10
PC Interface Software Kit 7002A840
Instruction Manual 920-SA-XT
Internal Battery Pack, with 4-pin Connector 5C2431-2
OPTIONAL ACCESSORIES
CAL-MN-C Calibration Combo, (M) N
CAL-FN-C Calibration Combo, (F) N
CAL-ME-C Calibration Combo, (M) 7/16 DIN
CAL-FE-C Calibration Combo, (F) 7/16 DIN
5012D Wideband Power Sensor 350 MHz -4000 MHz
5014 Directional Power Sensor 2 - 2700 MHz
5015 Terminating Power Sensor 40 MHz - 4000 MHz
5015EF Terminating Power Sensor 40 MHz - 12 GHz
5016D Wideband Power Sensor 350 MHz - 4000 MHz
5017D Wideband Power Sensor 25 MHz - 1000 MHz
5018D Wideband Power Sensor 150 MHz - 4000 MHz
5019D Wideband Power Sensor 25 MHz - 1000 MHz
7020-1-0101 Power Sensor 350 MHz - 4000 MHz
TC-MNMN-1.5 Test Cable, 1.5 m., N (M) conn.
TC-MNMN-3.0 Test Cable, 3 m., N (M) conn.
TC-MNFN-1.5 Test Cable, 1.5 m., N (M)/N (F) conn.
TC-MNFN-3.0 Test Cable, 3 m., N (M)/N (F) conn.
TC-MNME-1.5 Test Cable, 1.5 m., N (M) - 7/16 DIN (M)
TC-MNME-3.0 Test Cable, 3 m., N (M) - 7/16 DIN (M)
TC-MNFE-1.5 Test Cable, 1.5 m., N (M) - 7/16 DIN (F) conn.
TC-MNFE-3.0 Test Cable, 3 m., N (M) - 7/16 DIN (F) conn.
PA-MNME Adapter, N (M) to 7/16 DIN (M)
PA-FNME Adapter, N (F) to 7/16 DIN (M)
PA-MNFE Adapter, N (M) to 7/16 DIN (F)
PA-FNFE Adapter, N (F) to 7/16 DIN (F)
4240-550 Precision Connector Adapter Kit, 7/16 DIN, SA -Series
7002C870 Hard Shell Transit Case
SA-BATPAK-1 External Battery Pack
RPK5C2431-2 Battery, Spare
