SPECIFICATIONS
Frequency Range 100 kHz to 3.6 GHz
Frequency Resolution 1 Hz
Frequency Uncertainty ± 1 ppm
Reference Aging ± 1 ppm / year
Temperature Drift ± 1 ppm / °C
Spectral Purity -85 dBc @ 30 kHz
Sweep Time 2 s, full span; 1 ms, zero span
Resolution Bandwidth 100 Hz to 1 MHz RBW
Video Bandwidth 10 Hz to 300 kHz VBW
Amplitude Accuracy ± 1.0 dB typ, ± 1.5 dB max
Dynamic Range 66 dB, intermod-free
Noise Floor -135 dBm DANL
Attenuator 0, 10, 20, or 30 dB; internal
Pre-Amplifier +24 dB gain, internal
Data Points 705 displayed (settable)
Single Button
Measurement
Occ BW, Channel Power, ACPR, Field
Strength, AM/FM Demod, C/I
CE Compliant YES
RF Input, N(F) +20 dBm (100 mW) max
Connectivity Ethernet and USB 1.1
Operating & Store Temp 0° to 50°C oper; -20° to +80°C st
Humidity & Altitude 95% humidity; 4600 m altitude
Size and Weight 19” x 10” x 3.5”, 10 lbs
Emissions Mask IBOC, Analog FM, DTV and many others
Internal Storage 140 Gb
30303 Aurora Rd. Solon, OH 44139 866.695.4569 www.bird-technologies.com
Rack-Mount SignalHawk TM
SH-36S-RM
STANDARD ACCESSORIES
920-SHPC-OPS Operators Manual
920-SHPC-REF Start-Up Instructions
4421-055 AC Power Cord
5A2744-07 Ethernet Cable
5A2653-10 USB Cable, 10 ft, USB A (M) to USB B (M)
7002A148 CD, PC SignalHawk Emulator
OPTIONAL ACCESSORIES
100-SA-MFN-40 Attenuator, 100W, 40 dB, N(M) to N(F),
2.4 GHz
50-A-MFN-30 Attenuator, 50W, 30 dB, N(M) to N(F), 4 GHz
25-A-MFN-30 Attenuator, 25W, 30 dB, N(M) to N(F), 4 GHz
10-A-MFN-30 Attenuator, 10W, 30 dB, N(M) to N(F), 4 GHz
5-A-MFN-20 Attenuator, 5W, 20 dB, N(M) to N(F), 4 GHz
2-A-MFN-20 Attenuator, 2W, 20 dB, N(M) to N(F), 4 GHz
PA-MNME Adapter, N(M) to 7/16 DIN(M)
PA-FNME Adapter, N(F) to 7/16 DIN(M)
PA-MNFE Adapter, N(M) to 7/16 DIN(F)
PA-FNFE Adapter, N(F) to 7/16 DIN(F)
4240-550 Adapter Kit, 7/16 DIN
4240-500-1 Adapter Kit, N(F) to N(F)
4240-500-6 Adapter, N(F) to N(F)
4240-500-10 Adapter, N(M) to SMA(F)
Spare standard accessories are available as optional accessories.
Manuals and software/firmware updates available at
www.bird-technologies.com
