SPECIFICATIONS
Frequency Range 100 kHz to 3.6 GHz
Frequency Resolution 1 Hz
Frequency Uncertainty ± 1 ppm
Reference Aging ± 1 ppm / year
Temperature Drift ± 1 ppm / °C
Spectral Purity -85 dBc @ 30 kHz
Sweep Time 2 s, full span; 1 ms, zero span
Resolution Bandwidth 100 Hz to 1 MHz RBW
Video Bandwidth 10 Hz to 300 kHz VBW
Amplitude Accuracy ± 1.0 dB typ, ± 1.5 dB max
Dynamic Range 66 dB, intermod-free
Noise Floor -135 dBm DANL
Attenuator 0, 10, 20, or 30 dB; internal
Pre-Amplifier +24 dB gain, internal
Data Points 705 displayed (settable)
Single Button
Measurement
Occ BW, Channel Power, ACPR, Field
Strength, AM/FM Demod, C/I
Transit Drop Test 10 drops per MIL-PRF-28800F
CE Compliant YES
RF Input, N(F) +20 dBm (100 mW) max
Connectivity USB 1.1, TYPE B
Operating & Store Temp -10° to 50°C oper; -20° to +80°C st
Humidity & Altitude 95% humidity; 4600 m altitude
Size and Weight 7.5” x 7.0” x 3.0”, 4.5 lbs
Emissions Mask IBOC, Analog FM, DTV and many others
30303 Aurora Rd. Solon, OH 44139 866.695.4569 www.bird-technologies.com
PC SignalHawk TM
SH-36S-PC
STANDARD ACCESSORIES
920-SHPC-OPS Operators Manual
920-SHPC-REF Quick Start Card
5A2653-10 USB Cable, 10 ft, USB 2.0 certified, USB
A male to USB B male
5A2436 AC Power Supply
5A2238-2 Car Adapter
5B2431 Internal Li-Ion Battery, Field Replacement
7002A148 PC Hawk Emulator Software CD’s
Note: Spares of all standard accessories are also available as optional accessories
OPTIONAL ACCESSORIES
7002A224-1 Hard Carry Case
ANT-100 Antenna, 136 to 221
ANT-400 Antenna, 400 to 512
ANT-800 Antenna, 824 to 894
ANT-900 Antenna, 890 to 960
ANT-1800 Antenna, 1710 to 1880
ANT-1900 Antenna, 1850 to 1990
ANT-2400 Antenna, 2400 to 2500
100-SA-MFN-40 Attenuator, 100W, 40 dB, NM/NF, 2.4 GHz
50-A-MFN-30 Attenuator, 50W, 30 dB, NM/NF, 4 GHz
25-A-MFN-30 Attenuator, 25W, 30 dB, NM/NF, 4 GHz
10-A-MFN-30 Attenuator, 10W, 30 dB, NM/NF, 4 GHz
5-A-MFN-20 Attenuator, 5W, 20 dB, NM/NF, 4 GHz
2-A-MFN-20 Attenuator, 2W, 20 dB, NM/NF, 4 GHz
TC-MNFN-1.5 Test Cable, Phase Stable, 1.5 m, N(M) to N(F)
TC-MNFN-3.0 Test Cable, Phase Stable, 3.0 m, N(M) to N(F)
TC-MNMN-1.5 Test Cable, Phase Stable, 1.5 m, N(M) to N(M)
TC-MNMN-3.0 Test Cable, Phase Stable, 3.0 m, N(M) to N(M)
TC-MNFE-1.5 Test Cable, Phase Stable, 1.5 m, N(M) to
7/16 DIN(F)
TC-MNFE-3.0 Test Cable, Phase Stable, 3.0 m, N(M) to
7/16 DIN(F)
TC-MNME-1.5 Test Cable, Phase Stable, 1.5 m, N(M) to
7/16 DIN(M)
TC-MNME-3.0 Test Cable, Phase Stable, 3.0 m, N(M) to
7/16 DIN(M)
PA-MNME Adapter, N(M) to 7/16 DIN(M)
PA-FNME Adapter, N(F) to 7/16 DIN(M)
PA-MNFE Adapter, N(M) to 7/16 DIN(F)
PA-FNFE Adapter, N(F) to 7/16 DIN(F)
4240-550 Adapter Kit, 7/16 DIN
4240-500-1 Adapter, N(F) to N(F)
4240-500-6 Adapter, N(M) to N(M)
4240-500-10 Adapter, N(M) to SMA(F)*
Note: Recommend N(M) to SMA(F) Adapter Model 4240-500-10 for Antennas
