PAGE 27 TP10495
RECALL
(N) - (Y) ENTER
RECALL
(N) - (Y) ENTER
STORAGE
(N) - (Y) ENTER
9.2 Setting up a special fold.
This machine has 3 memory locations that can be
used to store special fold settings. These will store the plate
settings, the stacker wheel location, and the speed setting for
a fold.
9.2.1 To save a nonstandard fold in a memory
location 3
Set up the fold as you normally would. Once the speed
and folds are set the way you want, press a “MEMORY
SET” button. Recall will appear in the display. Press the
(-) button to get to the STORAGE screen.
9.2.2 Recall a fold saved in memory location.
Press the “MEMORY SET” button that corresponds
to the memory location you wish to recall. RECALL will
appear. Press the ENTER button.
9.3 Starting Production:
After the sheet length and the fold type has been
selected, production is started by:
Starting the main drive (press “DRIVE”),
·
The 2nd Station Drive must be started first then the
Parallel unit. The Parallel Unit will not start if the 2nd
Station Unit is not running.
·
Notes:
If the wrong “FOLD TYPE” button is pressed, you
can either press the “RESET” button instead of the
9.3 Continued
“ENTER” button or press the correct “FOLD TYPE” button,
then the “ENTER” button.
After every new set up the machine speed will always be
reset to 60%.
The fold type status LED, when lit constantly, indicates
that the fold plates are set for this type of fold.
Any time the folder is running and a change is made that
causes the fold plate stops to move; the main drive will stop.
