8.0 START UP
When power is applied, the system will first test all
LEDs, memory and display characters for 3 seconds.
After the self diagnostic phase, the display will show
the version number for 3 seconds.
If there are no error messages the display will go
to the jam detector screen if one of the jam detectors is
disabled. If none are disabled or after depressing enter, the
display will go to the initialization screen.
The initialization screen will remain for 10 seconds.
If the “+” button is not pressed during this time no initial-
ization will occur. The display will go to the count screen.
If there is any question about folding accuracy, re-ini-
tialize the system by turning off the power,then turn it back
on.
LEDs in the memory, or the fold type buttons will
light to indicate the last setting.
814MF
VERSION ****
FEEDER JAM DISABLED
INITIALIZATION
(+) YES (-) NO
TOTAL COUNT #######
I I I I I I I I I I I I I I I I I
I I I I I I I I I I I I I I I I I
SELECT FOLD
SHEET LENGTH ##.##
9.0 SETUP
Important note:
The operator control panel contains a numerical
keypad, which is automatically activated when a function
requires numerical data. The operator panel is color coded
to show this relationship. Numerical data is required for
Sheet length
Two pieces of information are required to setup a job,
assuming that initialization has previously been accomplished;
sheet length and fold type. Either order may be used. Select the
fold type first or the sheet length first
Note: When entering sheet length data use the length of
paper as it enters the 2nd Station Unit.
9.1 Setup for a standard fold
Method 1: Picking fold type first:
To setup for a new fold, press a fold type button. For
example, to set a “Z” fold, press the ”Z” fold button. The
display will show the last job sheet length. If the sheet length is
not correct, you will have 5 seconds to begin keying in the new
sheet length and press the “ENTER” button (see figure 1). If
the sheet length is correct, you may press the “ENTER” button
and not wait 5 seconds before proceeding.
