5.0 Automatic Operation
Contin.: Basic Display: Program Data
Conc. 1 Program Head shows: Conc.
5
Display of Additional functions
P:
S:
Program number of indicated program with memory segment
e.g. 1A = program 1, memory segment A and program
protection (asterisk)
Quantity of step numbers assigned by the program
Conc. 6
Display of the pictograph/s representing the Additional function/s
Status display "Actual machine function"
Display of the pictograph representing the actual machine function
Conc. 2 Program Data section shows: Conc. 7 Display section "Additional function"
e.g. 1 step number of program (with abbrev. for parti­
cular additional functions such as Eltrotact
etc.) Indication of the additional function to be stored after function has
been selected from menu.
Pictograph(s) additional function(s) stored:
Display of pictograph/s (symbol(s) of additional
function(s) stored Conc. 8 Pictographs user prompting
Indication of possible operating functions in the current menu
Conc. 3 Input section shows:
Data (cut size)/arithmetic functions entered
Conc. 9 Actual programming function with pictograph
Indication of current programming function as a plain text and as
a pictograph
Conc. 4 "Position display“ section shows:
ACTUAL POSITION Actual backgauge position/measuring unit
NOMINAL POSITION Indication of nominal position
Conc. 10 Scroll bar
For paging through the actual menu image; movement by cursor
keys
K5A - 4
