PAGE 43 TP10243-3
SCORING/SLITTING/PERFING
Your new folder is capable of many different applications that compliment the folding performance and provide for
greater productivity.
The folder is equipped with slitter shafts that are quickly set up for the required operation. These shafts accommodate
the mounting of the standard and optional accessories available that perform scoring, slitting and perforating functions.
1.0 Slitter Shaft Accessories Removal
To remove slitter shafts, remove knob (Figure 29-1). Insert knob into the center of the slitter housing (29-2) and remove
the housing, using the knob. Add or remove the parts needed for the current job using the wrench provided with the
machine. See the following pages for more information on perfing, scoring, and slitting. Reinstall slitter housing and knob
before starting the machine.
Figure 29
2 1
