PAGE 11 TP10243-3
Then Press the GREEN Button to lower Pile Feed Table. The Table will lower and stop
automatically in its lowest position
.
STARTING PRODUCTION WITH THE BAUM 2020
1. To START the Folder Drive, Press the GREEN Button on the Control Panel
just ABOVE the symbol, this will Start the Folder Drive and the Pump will automatically
come on.
2. To STOP the Folder Drive, Press the RED Button on the Control Panel just BELOW the
symbol or Press the RED EMERGENCY STOP Button on the Control Panel or on the
Stacker Control Panel. The Folder Drive will STOP, The Pump may continue to run for about 7
seconds. If you want to stop the pump at the same time as the folder drive press the Drive
STOP button twice within a 0.5 seconds.
The Pump circuit has a minimum ON time of 4 SECONDS. If the Pump is commanded OFF
within 4 seconds after it is started, it will continue run for the duration of the 4 seconds and then
shut OFF.
3. To Turn the Pump ON without the Folder Drive coming On, Press the GREEN Button ABOVE
the symbol
4. To Turn the Pump OFF, Press the RED Button BELOW the symbol NOTE: the Pump
will stay ON for at least 4 SECONDS before being able to shut off.
Easy Mode:
This mode is an automatic setup mode that sets the sheet gap to 1 inch and vacuum duration to 5
inches. Most jobs may be ran with this mode of operation. A Z-fold or a product with a window
will require the Continuous Mode of operation.
You can not change the sheet gap or vacuum
duration settings manually using the Easy-Mode. Only the DCT500 mode or Continuous Cycle
mode allows adjustment of these settings.
