BAUMFOLDER 2000 Series “ QUICK START” INSTRUCTIONS
TURNING THE MAIN SWITCH ON
When you turn on the Main Power Switch located on the side of the
Control Box , you must let the Control automatically run a self-test. During the
self-test D O NOT Press any buttons. Pressing of a button will cause an Error
Message to appear in the Main Display. To CLEAR Message turn Power OFF at
the Main Power Switch—WAIT
5 SECONDS, then turn Power back on.
1. Turn on Main Power Switch on left side of control enclosure.
-
Wait until control finishes self-test.
2. Load paper on Pile Feed Table. Press Pile up GREEN Button
Pile will raise automatically to correct height.
NOTE: To STOP Pile—Press RED Button
3. To START Drive Motor & Pump—Press GREEN Button ABOVE the
symbol.
To STOP Drive Motor ---Press RED Button BELOW the symbol or Press
EMERGENCY STOP BUTTON
RAISING AND LOWERING THE PILE FEEDER LIFT TABLE
1. After loading paper onto Pile Feeder Lift Table, Press the GREEN
Button
This will raise the paper to the proper feeding height automatically. You
can stop the Pile Feeder Lift Table by Pressing the RED Pile Feeder
STOP Button
2. To lower the Pile Feeder Table, you must first Press the RED Pile Feeder
STOP Button
