EL/GL SERIES (Mach 3) CONTROL WITH ML900 PANEL
The ML900 panel can be used with the EL8000, EL5000,
EL2000 and EL1000 systems. This user guide lists all
features that are available. Your spa may not respond as
described in this document as specific operation varies
by system and equipment used. If your spa is not fully
equipped, the panel buttons on your spa control may
not be laid out as shown.
The pump responsible for heating and filtration (pump 1
low on non-circ systems, or the circ pump on circ
systems) will be referred to simply as the pump.
Timeouts refer to a preset length of time that a
function is programmed to operate before shutting off
automatically. Certain conditions (filters or freeze) can
cause a function to operate longer, while faults can
cause a function to operate for a shorter length of time.
The system keeps track of timeouts regardless of other
conditions occurring.
In multi-button sequences, if buttons are pressed too
quickly in sequence, they may not register.
Table of Contents
EL/GL SERIES (Mach 3) CONTROL . . . . . 1
Initial Start-up . . . . . . . . . . . . . . . . . . . . . 1
Icon Legend . . . . . . . . . . . . . . . . . . . . . . 1
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Setting the Time . . . . . . . . . . . . . . . . . . . 2
Temp Set . . . . . . . . . . . . . . . . . . . . . . . . 2
Warm/Cool . . . . . . . . . . . . . . . . . . . . . . . 2
Mode/Prog . . . . . . . . . . . . . . . . . . . . . . . . 2
Standby Mode . . . . . . . . . . . . . . . . . . . . . 2
Jets 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Jets 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Jets 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Blower . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Invert . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preset Filter Cycles . . . . . . . . . . . . . . . . . 3
Optional Filter Cycle Programming . . . . . 3
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fiber . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Option . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Freeze Protection . . . . . . . . . . . . . . . . . . 4
Locking the Panel . . . . . . . . . . . . . . . . . . 4
Locking the Set Temperature . . . . . . . . . . 4
Clean-up Cycle . . . . . . . . . . . . . . . . . . . . 4
Circ Pump . . . . . . . . . . . . . . . . . . . . . . . . 4
Ozone . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Displaying Information About Your Spa . . 5
User Preferences . . . . . . . . . . . . . . . . . . . 5
Editing User Preferences . . . . . . . . . . . . . 5
Diagnostic Messages . . . . . . . . . . . . . . 6-7
Periodic Reminder Messages . . . . . . . . . . 8
GFCI Protection . . . . . . . . . . . . . . . . . . . . 8
GFCI Trip Test Procedure . . . . . . . . . . . . 8
Optional Auxiliary Panels . . . . . . . . . . . . 9
Basic Installation Guidelines . . . . . . . . . 10
CSA Compliance . . . . . . . . . . . . . . . . . . 10
Page 1
Initial Start-up
When your spa is first actuated, it will go into Priming
mode (after displaying some configuration information).
Please see the M-7 Installation Instruction Manual for
complete instructions on Power-up and Pump Priming. The Priming mode will last for up to 4 minutes and
then the spa will begin to heat and maintain the water
temperature in the Standard mode. You can exit Priming
mode early by pressing “Warm” or “Cool.”
Jets Icon - Spins fast on high speed; spins
slow on low speed. Light Icon - On dim, the LCD will show
the center circle plus one quarter of the
light beams. Half of the light beams will
show on medium brightness, and all of
the light beams will show on bright.
Fiber-Optic Light Icon - Spins when the
wheel is on; stands still when wheel is off. Heat Icon - Indicates different stages of heating.
Icon Legend
Blower Icon - Biggest in highest speed;
smallest in lowest speed.
