12. USA pull up/pull down (+/-0.1%)
13. European pull up/pull down (+/- 4%)
14. Status LEDs
LOCK
ATOMIC
OVEN
15. INFO Button
16. HD Pull Down Select Buttons
17. SD Video Select Button
When in edit mode, this button toggles +/- 0.1% pull up/pull down for the channel(s)
being edited. To confirm an edit press the SAMPLE RATE knob (4). On the triple
display for the given channel(s), the top line of the digit to the far right is lit for a pull
up, and the bottom line is lit for a pull down.
When in edit mode, this button toggles +/- 4% pull up/pull down for the channel(s)
being edited. To confirm an edit press the SAMPLE RATE knob (4). On the triple
display for the given channel(s), the top line of the digit to the far right is lit for a pull
up, and the bottom line is lit for a pull down.
When lit, indicates that Trinity is locked to a valid incoming reference.
The light will flash if there is no input, or a frequency present at the input is not
one of the recognized valid gearboxing frequencies as in Appendix A
.
Will be lit if SOURCE is set to OVEN, and a valid signal is present at the
rear panel atomic input.
Flashes when Trinity is first turned on, and will light solid when the oven
reaches its operating temperature.
Press to display further information on the SOURCE. Press again, or wait ten
seconds to return.
Toggles -0.1% pull down On or Off for each HD channel. Press HD button for the
given channel(s) to confirm edit(s).
Use this button to select the format that will be present at rear panel outputs SD 3 &
4. This is an instant change that doesn't require confirmation
Notes:
Notes:
Note:
If 0.1% & 4% pull ups are selected, the middle and top line of the last digit on the display are lit.
If 0.1% & 4% pull downs are selected, the middle and bottom line of the last digit in the display
are lit.
If 0.1% & 4% pull ups are selected, the middle and top line of the last digit on the display are lit.
If 0.1% & 4% pull downs are selected, the middle and bottom line of the last digit in the display
are lit.
In normal operation OVEN and LOCK or ATOMIC and LOCK will not be lit at the same
time. However, when using the advanced SPLIT mode this is possible.
