GETTING STARTED

It only takes a few moments to harness the benefits of the Isochrone Trinity.

Connect Trinity to an AC or DC power source via rear panel connectors

Power on using front panel power button (1).

To use Trinity's internal clock, set SOURCE knob (3) to OVEN, and press to

confirm. If slaving to an external source, connect the master sync device to an
input on the rear panel, and select the corresponding position with the
SOURCE knob (3). Press to confirm.

Set sample rate: Press AUDIO A button (6) to allow the sample rate to be

changed on Audio channel A. Select desired sample rate with SAMPLE RATE
knob (4) , and press to confirm.

Note:

If using internal OVEN, there is a warm up period when the unit is first powered on.

Pressing the INFO button just after powering on when SOURCE is set to OVEN will show the
OVEN heating up. Correct operating temperature is reached when the OVEN light

is lit

solid.

When making initial connections, it is advised to do so with the studio volume

turned down. Some devices may emit an unpleasant sound until properly configured
to accept incoming clock.

Trinity is now providing your chosen clock sample rate to Audio outputs A. You can
also use Audio channels B and C in the same way. It is also possible to edit all

udio channels together so that one frequency is sent to all outputs on all channels.

Some devices will automatically sync to clock coming from Trinity. Some will
require that you set them to external clock manually. Other devices may require
additional configuration to be able to sync to the incoming clock. Please consult
the operating manual(s) of your device(s) regarding external clocking.
