9 AJA FR1 and FR2 Video Card Frames User Manual
FR1/FR2 Power
Monitoring The power supply outputs can be monitored via the RJ45 connector on the rear panel.
The following diagram shows the pinouts where supply values can be measured.
Pinout for RJ45 Connector On Rear Panel
Physical Dimensions Width: 19”
Height: 3.5”
Depth: 13”
Rack Units: 2
Compatibility Leitch™ 6800-series
Options FR2-PS Power Supply Module for FR2 Frame
Models FR2—FR2 frame with one FR2-PS power supply
FR2-D—FR2 frame with dual power supplies
FR2-PS—FR2 Power supply
Item Specification
1
2
3
4
5
6
7
8
-6.5 Volts PS2
-6.5 Volts PS1
Ground
Serial Com Port
Serial Com Port
Ground
+6.5 Volts PS2
+6.5 Volts PS1
RJ45 Connector on Rear Panel Description
Pin Numbers
