8
Note: FR1 power supply replacement requires disassembly of the chassis frame. It
is not user-serviceable; power supply replacement should be referred to a qualified
AJA service center.
Warning!
Disconnect the external AC power supply line cord(s) from the mains power
before moving the unit.
Specifications
FR1 Specifications
FR2 Specifications
Item Specification
Capacity 4 slots, 1 Rack Unit
Inputs • Group of 9 BNCs (I/O) for each module (4 groups)
• Reference Input BNC
Power 50 Watt Capacity
Universal Input 90-240 VAC Power Supply
Optional Redundant Power Supply, Diode-Isolated
Cooling Dual fan, forced-air
Physical Dimensions Width: 19”
Height: 1.75”
Depth: 14.75”
Rack Units: 1
Compatibility Leitch™ 6800-series
Options FR1-PS Power Supply Module for FR1 Frame
Models FR1—FR1 frame with one power supply
FR1-D—FR1 frame with two (redundant) power supplies
Item Specification
Capacity 10 slots, 2 Rack Units
Inputs • Group of 9 BNCs (I/O) for each module (10 groups)
• Reference Input BNC, active DA to all slots
Power 100 Watt Capacity
Universal Input 90-240 VAC Power Supply
Optional Redundant Power Supply, Diode-Isolated
Cooling 3-fan, forced-air
