Installation
Typically, D10CE installation consists of the following:
1. disconnect +5VDC from the convertor
2. configure the DIP switch for the desired equipment configuration and video formats
3. connect video equipment to the convertor BNCs
4. apply +5VDC power to the converter ((AJA power supply model DWP)
Specifications
Item Specification
Serial Input SMPTE 259M 270MB, (SDI)
SDI Cable Equalization 300 meter 8281 typical
Serial Outputs Equalized, Re-clocked
Frequency Response +/- .15dB to 5.5MHz (Y)
+/- .15dB to 2.5MHz (Chroma - Component, RGB)
+/- .15dB to 1.3MHz (Chroma - Composite)
2T K factor < 0.5% (Y)
Differential Gain < 1 .5%
Differential Phase < 1 .5 degree
Y/C delay 10ns maximum
D/A Converters 10 bits, 4X oversampling
Signal Path 10 bits
Delay (input to output) 2.5us
Output level adjustment +/- 20% (internal)
Output level matching 1 .5% or 10mv (All outputs are separately buffered)
Power
(AJA power supply model DWP) 5v DC regulated, 4 watt
Size 147 x 79 x 25 mm
