7 AJA D10CE 10-bit SDI to Component/Composite Converter User Manual — User Controls
Switch 7 Configure Blanking For Component Output BNCs (3)
:
Switch 8 Configure Digital Noise Reduction
:
Output Selection
Matrix For Output
2 (3 BNCs) The following table shows the combinations of DIP switch settings required to configure the
three BNCs below the COMPOSITE/SYNC BNC.
ON OFF
WIDE Blanking:
Vertical—
Line numbers indicate where video starts)
line 20, field 1; line 20, field 2 (525 line)
line 23, field 1; line 336, field 2 (625 line)
Horizontal—
Active video line duration
ITU-R/SMPTE (710 pixels NTSC,
702 pixels PAL) NARROW (NAR) Blanking:
Vertical—
Line numbers indicate where video starts
line 13, field 1; line 12, field 2 (525 line)
line 10, field 1; line 322, field 2 (625 line)
Horizontal—
Active video line duration's)
ITU-R.470 (720 pixels PAUNTSC)~-
ON OFF
Enables Digital Noise Reduction on input. Disables Digital Noise Reduction
Output Format
DIP Switch
#4
DIP Switch
#5
DIP Switch
#6
1 Composite and 1 Y/C (Pedestal) CMPSTE N/A ON
1 Composite and 1 Y/C (no pedestal) CMPSTE N/A OFF
RGB COMPNT RGB OFF
RGB with pedestal COMPNT RGB ON
SMPTE component (BETA625)/
EBU-N10 COMPNT YPbPr/YC OFF
BETA 525 component COMPNT YPbPr/YC ON
