Switch 3 Configure Blanking For Composite/Sync BNC
:
Switch 4 Select Composite (CMPSTE) or Component (COMPNT)
Out
:
Switch 5 Select Video Format of Component Outputs
:
Switch 6 Configure Pedestal For Component Output BNCs (3)
:
Note: There is no effect with 625 input.
ON OFF
WIDE Blanking:
Vertical—
Line numbers indicate where video starts)
line 20, field 1; line 20, field 2 (525 line)
line 23, field 1; line 336, field 2 (625 line)
Horizontal—
Active video line duration
ITU-R/SMPTE (710 pixels NTSC,
702 pixels PAL) NARROW (NAR) Blanking:
Vertical—
Line numbers indicate where video starts
line 13, field 1; line 12, field 2 (525 line)
line 10, field 1; line 322, field 2 (625 line)
Horizontal—
Active video line duration's)
ITU-R.470 (720 pixels PAUNTSC)~-
ON OFF
COMPNT:
Selects component video output CMPSTE:
Selects composite video output
ON OFF
YUVNC:
Selects YPbPr/YC component output, if SW1
is set to “COMPNT,” RGB:
Selects RGB component output, if SW1 is set to
“COMPNT”
ON OFF
7.5 IRE pedestal for NTSC (also selects
BETA 525 levels for YPbPr) No pedestal (also selects SMPTE levels for YPbPr)
