AJA RD5CE Dual Universal D/A Converter User Manual
Introduction
The AJA Video RD5CE is a low-cost, dual-channel, universal video D/A
converter. The RD5CE supports 2 completely separate channels of SDI to
analog conversion. Channel 1 can output component or composite analog
video including YPbPr (SMPTE, EBU-N10), Betacam, RGB, composite or YC (S-
Video). Channel 2 can output composite or Y. Both SDI inputs have a reclocked
SDI loop-thru output. The RD5CE fits in AJA's R-Series Frames or other standard
industry rack mount frames.
Features
RD5CE Card Module, Side View
•
Low Cost, Universal D/A Conversion
•
Two Separate Channels
•
SDI Inputs, Re-Clocked Loop-Thru SDI Outputs
•
CH 1 Outputs Component or Composite
•
CH 2 Outputs Composite or Y
