Both the switch numbers and labels are both shown in the table, with the labels in
parentheses (for example, switch 4 is labeled “FORMAT” and switch 8 is labeled “S3”). The
SW 8, SW7, and SW 6 switches form a binary value shown in the left hand columns., with
the DIP switch direction indicated by:
• 0 = Switch LEFT
• 1 = Switch RIGHT
NOTE: For 1080psf29.97 use 1080i59.94, for 1080psf30 use 1080i60, and for 1080psf25 use
1080i50.
Table 2. HD Formats Set with DIP Switches 4 through 8
SW4 (FORMAT) 59.94 50
SW5 (HD FMT) 1080 720 1080 720
SW8
(S3)
SW7
(S2)
SW6
(S1)
0 0 0 1080i59.94
1080psf29.97 720p59.94 1080i50 720p50
0 0 1 1080psf23.98 720p23.98 1080i50 720p25
0 1 0 1080p23.98 720p23.98 1080p25 720p25
0 1 1 1080p29.97 720p29.97 1080p25 720p25
1 0 0 1080i60
1080psf30 720p60 1080i50
1080psf25 720p50
1 0 1 1080psf24 720p24 1080i50 720p25
1 1 0 1080p24 720p24 1080p25 720p25
1 1 1 1080p30 720p30 1080p25 720p25
