9. Service Mode

9.15.3 DMD

How to select the overview?

1. Push the cursor key ↑ or ↓ to highlight DMD. (menu 9-42)

2. Press ENTER to select.

An overview of the working of the DMD’s will be displayed. (menu 9-43)

DIAGNOSIS

I2C

DMD

SMPS
LPS1
LPS2
LPS3

VOLTAGES
FANSPEED

Select with

or

then

to return

Menu 9-42

DMD

STATUS RED

OK

STATUS GREEN

OK

STATUS BLUE

OK

to return.

Menu 9-43

9.15.4 SMPS

How to select the overview?

1. Push the cursor key ↑ or ↓ to highlight SMPS. (menu 9-44)

2. Press ENTER to select.

The SMPS overview menu will be displayed. (menu 9-45)

DIAGNOSIS

I2C
DMD

SMPS

LPS1
LPS2
LPS3

VOLTAGES
FANSPEED

Select with

or

then

to return

Menu 9-44

SMPS

µC VERSION

03.01

EEPROM VERSION

03.00

Internal T.

26(45)C

NTC T.

38(80)C

Internal temp.

OK

NTC

OK

TILT SWITCH

OK

MICRO SWITCH

OK

LAMP TEMP

OK

LPS MAINS

OK

SMPS OUTPUT

OK

to return

Menu 9-45

9.15.5 LPS (lamp power supply)

How to select the overview?

1. Push the cursor key ↑ or ↓ to highlight LPS. (menu 9-46)

2. Press ENTER to select.

The LPS overview menu will be displayed. (menu 9-47)

DIAGNOSIS

I2C
DMD

SMPS

LPS1

LPS2
LPS3

VOLTAGES
FANSPEED

Select with

or

then

to return

Menu 9-46

LPS1

µC Version

02.01

EEPROM Version

01.11

Internal T.

029(075)C

Rectifier T.

037(105)C

Heats. PFC T.

029(100)C

Heats. LPS T.

028(100)C

Trafo T.

032(105)C

I2C

OK

to return

Menu 9-47
