—17—
DETAILED COOLING CAPACITIES* Continued
See notes on page 19.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
533AN042-A Outdoor Section With CK5AA048 Indoor Section
1225
72 46.5 23.0 3.09 45.1 22.7 3.44 43.0 21.9 3.81 40.7 21.2 4.23 38.1 20.3 4.69 35.2 19.4 5.20
67 44.0 30.4 3.06 41.9 29.6 3.39 39.6 28.6 3.77 37.3 27.7 4.17 34.4 26.6 4.61 30.2 25.0 5.09
63†† 38.6 28.5 2.98 35.8 27.3 3.29 33.1 26.2 3.64 31.8 25.6 4.06 30.2 25.0 4.53 26.6 23.5 4.99
62 38.1 35.8 2.97 35.4 34.4 3.29 33.1 33.1 3.64 32.0 32.0 4.07 30.7 30.7 4.54 28.1 28.1 5.03
57 37.3 37.3 2.96 35.1 35.1 3.28 33.8 33.8 3.65 32.4 32.4 4.08 30.8 30.8 4.54 28.1 28.1 5.03
1400
72 47.1 23.9 3.16 45.3 23.3 3.50 43.2 22.7 3.88 41.0 22.0 4.30 38.4 21.2 4.75 35.6 20.4 5.29
67 44.5 32.0 3.13 42.2 31.0 3.46 40.0 30.2 3.83 37.8 29.5 4.24 35.2 28.6 4.70 30.9 27.0 5.18
63†† 39.7 30.5 3.07 36.8 29.3 3.38 34.4 28.3 3.74 33.1 27.7 4.16 31.2 26.9 4.61 27.6 25.4 5.08
62 39.2 38.4 3.06 37.7 37.5 3.39 35.5 35.5 3.76 34.4 34.4 4.19 32.8 32.8 4.64 29.8 29.8 5.14
57 38.9 38.9 3.05 37.6 37.6 3.39 36.2 36.2 3.77 34.8 34.8 4.20 32.4 32.4 4.64 29.6 29.6 5.14
1575
72 47.6 24.7 3.24 45.9 24.3 3.59 43.7 23.7 3.96 41.4 23.0 4.38 38.7 22.2 4.84 35.8 21.4 5.38
67 44.9 33.4 3.20 42.5 32.5 3.53 40.4 31.9 3.90 38.1 31.1 4.31 35.6 30.4 4.78 31.6 28.8 5.26
63†† 41.0 32.5 3.15 39.1 31.7 3.48 35.9 30.4 3.83 34.2 29.7 4.25 32.0 28.7 4.70 28.0 27.0 5.17
62 41.5 41.3 3.16 39.9 39.9 3.50 37.6 37.6 3.87 36.5 36.5 4.29 34.0 34.0 4.74 31.0 31.0 5.24
57 41.3 41.3 3.16 39.8 39.8 3.49 38.4 38.4 3.88 36.5 36.5 4.29 33.8 33.8 4.74 30.9 30.9 5.24
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 042 0.99 1.00 CK5A/CK5BA 042 0.98 0.92
CC5A/CD5AC 048 0.99 1.00 CK5A/CK5BW 048 0.99 0.92
CC5A/CD5AW 042 0.99 1.00 COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
048 1.00 1.00 CC5A/CD5AA 042 0.98 0.93
CD5AA 048 1.00 1.00 CC5A/CD5AW 048 0.99 0.92
CE3AA 042 0.99 1.00 CK5A/CK5BA 042 0.98 0.93
048 1.00 1.00 CK5A/CK5BW 048 0.99 0.92
CF5AA 048 0.99 1.00 COILS + 355MAV042040 VARIABLE SPEED FURNACE
CK3BA 042 0.99 1.00 CC5A/CD5AA 042 0.98 0.95
048 1.00 1.00 CC5A/CD5AW 048 0.99 0.95
CK5A/CK5BA 042 0.99 1.00 CK5A/CK5BA 042 0.98 0.95
048 1.00 1.00 CK5A/CK5BW 048 0.99 0.95
CK5A/CK5BN 048 0.99 1.00 COILS + 355MAV042060 VARIABLE SPEED FURNACE
CK5A/CK5BT 042 0.99 1.00 CK3BA 042 0.98 0.95
048 1.00 1.00 COILS + 355MAV042080 VARIABLE SPEED FURNACE
CK5A/CK5BW 048 1.00 1.00 CC5A/CD5AA 042 0.98 0.94
F(A,B)4AN(F,B,C) 042 0.99 1.01 CD5AA 048 0.99 0.94
048 1.00 1.02 CK3BA 042 0.98 0.94
FC4BN(F,B) 042 0.98 1.00 048 0.99 0.94
048 0.99 1.00 CK5A/CK5BA 042 0.98 0.94
FC4BNB 054 1.01 0.99 048 0.99 0.94
FG3AAA 048 1.00 1.00 COILS + 355MAV060080 VARIABLE SPEED FURNACE
FK4CNB 006 1.01 0.90 CC5A/CD5AA 042 0.98 0.95
FK4CNF 003 0.96 0.91 CD5AA 048 0.99 0.95
005 1.00 0.92 CK3BA 042 0.98 0.95
FV4ANB 006 1.01 0.90 048 0.99 0.95
FV4ANF 003 0.96 0.91 CK5A/CK5BA 042 0.98 0.95
005 1.01 0.92 048 0.99 0.95
FX4ANF 042 0.96 1.00 COILS + 355MAV060100 VARIABLE SPEED FURNACE
048 0.99 1.00 CC5A/CD5AA 042 0.98 0.93
COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE CD5AA 048 0.99 0.93
CC5A/CD5AA 042 0.98 0.94 CK3BA 042 0.98 0.93
CD5AA 048 0.99 0.94 CK5A/CK5BA 042 0.98 0.93
CK3BA 042 0.98 0.94 048 0.99 0.93
048 0.99 0.94 COILS + 355MAV060120 VARIABLE SPEED FURNACE
CK5A/CK5BA 042 0.98 0.94 CC5A/CD5AA 042 0.98 0.93
048 0.99 0.94 CC5A/CD5AW 048 0.99 0.93
COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE CK5A/CK5BA 042 0.98 0.93
CC5A/CD5AA 042 0.98 0.92 CK5A/CK5BW 048 0.99 0.93
CC5A/CD5AW 048 0.99 0.92 — — —
