—16—
DETAILED COOLING CAPACITIES* Continued
See notes on page 19.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
533AN036-A Outdoor Section With CK5AA042 Indoor Section
1050
72 40.6 20.1 2.70 39.1 19.6 3.00 37.3 19.0 3.33 35.3 18.3 3.70 33.0 17.6 4.08 30.5 16.8 4.52
67 38.2 26.3 2.68 36.3 25.5 2.98 34.5 24.8 3.30 32.4 24.0 3.66 30.2 23.2 4.04 26.5 21.9 4.43
63†† 35.9 25.8 2.67 34.1 25.1 2.96 32.0 24.1 3.27 29.6 23.1 3.62 26.8 21.9 3.97 23.4 20.5 4.35
62 35.4 32.2 2.67 32.6 30.8 2.94 29.7 29.4 3.24 28.2 28.2 3.59 26.8 26.8 3.98 24.9 24.9 4.39
57 33.6 33.6 2.64 31.7 31.7 2.92 29.6 29.6 3.23 28.3 28.3 3.59 26.9 26.9 3.98 24.6 24.6 4.38
1200
72 41.1 20.8 2.76 39.6 20.3 3.06 37.8 19.8 3.40 35.7 19.2 3.76 33.4 18.4 4.15 30.8 17.7 4.59
67 38.9 27.8 2.75 36.9 27.0 3.04 35.0 26.4 3.37 32.9 25.6 3.72 30.6 24.9 4.11 26.9 23.5 4.50
63†† 36.6 27.4 2.73 34.7 26.6 3.02 32.5 25.7 3.34 30.1 24.7 3.68 27.2 23.5 4.04 23.7 22.0 4.42
62 36.2 34.5 2.73 33.4 33.0 3.00 31.7 31.7 3.32 30.2 30.2 3.68 28.7 28.7 4.07 25.9 25.9 4.47
57 35.0 35.0 2.71 33.9 33.9 3.01 31.8 31.8 3.32 30.5 30.5 3.69 29.0 29.0 4.08 25.9 25.9 4.47
1350
72 41.4 21.4 2.82 39.9 21.0 3.13 38.1 20.5 3.46 36.0 19.9 3.82 33.7 19.2 4.22 31.0 18.6 4.65
67 39.1 29.0 2.80 37.4 28.5 3.10 35.4 27.8 3.43 33.3 27.1 3.78 31.0 26.5 4.18 27.5 25.1 4.58
63†† 37.0 28.8 2.79 35.2 28.1 3.08 32.9 27.1 3.40 30.4 26.1 3.74 27.5 24.9 4.11 24.1 23.4 4.49
62 37.0 36.5 2.79 35.4 35.4 3.09 33.6 33.6 3.41 31.8 31.8 3.76 29.8 29.8 4.16 26.7 26.7 4.56
57 36.9 36.9 2.79 35.4 35.4 3.09 33.7 33.7 3.41 31.8 31.8 3.76 29.8 29.8 4.16 27.0 27.0 4.56
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 036 1.00 1.00 COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
042 1.00 1.00 CC5A/CD5AA 042 0.99 0.92
CC5A/CD5AW 036 1.00 1.00 CC5A/CD5AW 036 0.99 0.92
042 0.99 1.00 CK5A/CK5BA 042 0.99 0.92
CE3AA 036 0.99 1.00 CK5A/CK5BW 036 0.99 0.92
042 1.00 1.00 COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
CF5AA 036 0.99 1.00 CC5A/CD5AA 042 0.99 0.92
CK3BA 036 1.00 1.00 CC5A/CD5AW 036 0.99 0.92
042 1.00 1.00 CK5A/CK5BA 042 0.99 0.92
CK5A/CK5BA 036 1.00 1.00 CK5A/CK5BW 036 0.99 0.92
CK5A/CK5BN 042 1.00 1.00 COILS + 355MAV042040 VARIABLE SPEED FURNACE
CK5A/CK5BT 036 1.00 1.00 CC5A/CD5AA 042 0.99 0.93
042 1.00 1.00 CC5A/CD5AW 036 0.99 0.94
CK5A/CK5BW 036 1.00 1.00 CK5A/CK5BA 042 0.99 0.93
F(A,B)4AN(F,B,C) 042 1.00 1.01 CK5A/CK5BW 036 0.99 0.94
F(A,B)4AN(F,C) 036 0.97 1.02 COILS + 355MAV042060 VARIABLE SPEED FURNACE
FC4BN(F,B) 042 1.00 1.00 CC5A/CD5AA 036 0.99 0.94
FCBNF 036 0.97 1.01 CK3BA 036 0.99 0.94
FG3AAA 036 0.97 1.00 CK5A/CK5BA 036 0.99 0.94
FK4CNB 006 1.01 0.90 COILS + 355MAV042080 VARIABLE SPEED FURNACE
FK4CNF 001 0.97 0.94 CC5A/CD5AA 042 0.99 0.93
002 0.97 0.94 CC5A/CD5AW 036 0.99 0.93
003 0.98 0.91 042 0.99 0.93
005 1.00 0.91 CK5A/CK5BA 042 0.99 0.93
FV4ANB 006 1.02 0.90 CK5A/CK5BW 036 0.99 0.93
FV4ANF 002 0.97 0.94 COILS + 355MAV060080 VARIABLE SPEED FURNACE
003 0.98 0.91 CC5A/CD5AA 042 0.99 0.93
005 1.00 0.91 CC5A/CD5AW 036 0.99 0.94
FX4ANF 042 0.97 1.00 042 0.99 0.93
COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE CK5A/CK5BA 042 0.99 0.94
CC5A/CD5AA 036 0.99 0.95 CK5A/CK5BW 036 0.99 0.94
CK3BA 036 0.99 0.95 COILS + 355MAV060100 VARIABLE SPEED FURNACE
CK5A/CK5BA 036 0.99 0.95 CC5A/CD5AA 042 0.99 0.92
COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE CC5A/CD5AW 036 0.99 0.92
CC5A/CD5AA 042 0.99 0.93 042 0.99 0.92
CC5A/CD5AW 036 0.99 0.94 CK5A/CK5BA 042 0.99 0.92
042 0.99 0.93 CK5A/CK5BW 036 0.99 0.92
CK3BA 042 0.99 0.93 COILS + 355MAV060120 VARIABLE SPEED FURNACE
CK5A/CK5BA 042 0.99 0.93 CC5A/CD5AA 042 0.99 0.92
CK5A/CK5BW 036 0.99 0.94 CC5A/CD5AW 036 0.99 0.92
— — — CK5A/CK5BA 042 0.99 0.92
CK5A/CK5BW 036 0.99 0.92
