BLODGETT OVEN COMPANY, 50 Lakeside Avenue, Burlington, Vermont 05401 USA
Telephone: (802) 860-3700 (800) 331-5842 Fax: (802) 860-3732
EXCLUSIVE TO EXPORT
Ref.
Part
No.
No.
Description
37
M8518
Controller, Temperature Gen Exp & CE
3
M6811
Control, Minarik Closed Loop (Qty 1)
Gen Exp & CE
5
M5446
Potentiometer, Control (Qty 1)
Gen Exp & CE
38
M8537
Control Decal Gen Exp & CE
M7862
Harness,Control Box CE
11
M9562
Element Assy., 230/400V, 3PH
11
M9567
Element Assy., 208V, 3PH (Qty 1)
11
M9568
Element Assy., 240V, 3PH (Qty 1)
7
M5447
Indicator Lamp, 250V (Qty 1) Gen Exp & CE
15
M6044
Snap Disc, L110-20F, 3 Pole (Qty 1)
(Control Compartment) Gen Exp & CE
6
M6087
Knob, Low Profile (Qty 1) Gen Exp & CE
8
30465
Switch, Rocker DPDT Black (Qty 1)
Gen Exp & CE
13
M6899
Transformer 208/240V
1
M7389
Timer, Solid State Off Delay, 5 AMP, 230V
19634
Contactor, Mercury 3 Pole, 30AMP
M4542
Block, Power Terminal
R0166
Block, Terminal Ground
42
M7983
Filter, EMI 20A, 250V, 50/60hz, 2 leads
(Qty 1in all CE ovens) CE
M8521
Filter, EMI 2A, 50V, DC, 4 leads
(Qty 1 in all CE ovens) CE
43
M7984
Capacitor, 250V (Qty 1) CE
M7888
Relay, 1 Sec Delay CE
M8592
Fuse, Gen Exp 5 AMP
M3167
Fuseholder, Type HTB-36M
M8660
Fuse, Gen Exp 2 AMP
M8670
Fuse, Gen Exp 1.6 AMP
M8559
Phase Conv. Kit 230V 1PH to 230/240V
3PH CE
M8573
Phase Conv. Kit 1PH to 3PH NON CE
NOTE:
Cord set is not available on CE ovens.
EXTERIOR COMPONENTS
Ref.
Part
No.
No.
Description
31
M7116
Crumb Pan, Drive (Qty 1)
32
M7118
Crumb Pan, Idle, Sgl Section (Qty 1)
33
M7117
Crumb Pan, Idle, Top Section (Vented)
(Qty 1)
34
M6925
Air Curtain, Drive Side (Qty 1)
35
M6945
Air Curtain, Idle Side (Qty 1)
M6792
Product Stop (Qty 1)
36
M10056
Product Extension, Drive & Idle Side
(Qty 2 per oven)
38
M7568
Decal, Control Panel (w/o Fan Controls)
(Qty 1)
39
M7586
Control Cover Assy. (Stationary) (Qty 1)
40
M7585
Access Door, Control Cover Assy. (Qty 1)
M7651
Latch, Access Door (Qty 1)
90086
Nameplate, Blodgett 7-3/4" (Qty 1)
M7887
Pin, Stacking (Qty 4)
M9084
Heat Shield Kit (Qty 1)
M10119
Stacking Kit
M7195
Chimney Kit, Sgl (Qty 1)
M7196
Chimney Kit, Dbl (Qty 1)
M4852
Body Back (Qty 1)
41
20435
Legs, 4" w/ Bolts, S/S (Set of 4)
M5953
Stand, 24" S/S w/ Casters
MARCH 12, 2001
5
MT1820
