MT1820E
March 12, 2001
þ ASAP Distributor Required Stocking Parts
t Doors Are Not Returnable
IMPORTANT: When ordering parts, please provide the model, gas type
and serial number of the oven. The identification plate is located on
the left side of the combustion compartment and, also, above the control
panel under the ledge.
2
ELECTRICAL COMPONENTS
Ref. Part
No. No. Description
1 þ M7389 Timer, Solid State (Qty 1)
2 þ M5442 Control, Temperature (Qty 1)
3 þ M6811 Control, Minarik Closed Loop (Qty 1)
(for Gearmotor)
4 þ 30857 Probe, Temperature RTD 500 Ohms (Qty 1)
M7252 Bracket, EGO Probe (Qty 1)
5 þ M5446 Potentiometer, Control (Qty 1)
6 þ M6087 Knob, Low Profile (Qty 1)
7 M5447 Indicator Lamp, 250V (Qty 1)
8 þ 30465 Switch, Rocker DPDT Black (Qty 1)
9 þ M3295 Thermostat, High Limit (Qty 1)
þ M4988 Fuse, 5 AMP, 300V, SC-5 (Qty 2)
10 þ M0158 Fuse Holder (Qty 2)
11 þ M9559 Element Assy, 208V, 1 PH (Qty 1)
11 þ M9560 Element Assy, 240V, 1 PH (Qty 1)
11 M9561 Element Assy, 230V, 1 PH (Qty 1)
M8576 Voltage Conversion Kit (208 to 240V)
M8577 Voltage Conversion Kit (240 to 208V)
12 þ M5765 Relay, Heat Sink Assy. (Qty 1)
13 þ M6899 Transformer, 208/240V to 24V (Qty 1)
M3299 Bracket, Thermal Switch (Qty 1)
14 þ M2453 Snap Disc, L140-20F, 3 Pole (Qty 1)
(Blower Compartment)
15 þ M6044 Snap Disc, L110-20F, 3 Pole (Qty 1)
(Control Compartment)
16 M0593 Terminal Block, 2 Pole (Qty 3)
17 M10336 Terminal Block to Din Rail Conv Kit
Replaces 11204 this oven only
18 þ 23034 Axial Fan, 106 CFM, 230V 4" (Qty 5)
19 22718 Guard, Axial Fan (Qty 3)
M10434 Cord Set Assy., 40 AMP, 250V (Qty 1)
4888 Lug, Grounding (Qty 1)
20 M7265 Connector, Liquid Tight (Qty 1)
19634 Contactor, Mercury, 3Pole, 30AMP
M9478 Conversion Kit, SS Relay to Merc. Contactor
18651 Contactor, Mercury, 2 Pole, 60AMP
M3831 Harness, Elements to Contactor
CONVECTION COMPONENTS
Ref. Part
No. No. Description
28 þ M7233 Motor, Blower Assy., CW, 50/60 HZ (Qty 2)
M7577 Insulation Kit, Blower (Qty 1)
29 M7961 Air Plate, Upper (Qty 1)
30 M7960 Air Plate, Lower (Qty 1)
CONVEYOR COMPONENTS
Ref. Part
No. No. Description
21 M6337 Belt, Wire S/S 18" (Per Foot)
(Total Length 9 FT)
22 þ M7994 Motor, Gear w/ Encoder (Qty 1) Motor Only
M7995 Cable, Encoder (for Motor M7994)
(with molex connector at each end)
23 M7043 Conveyor Assy. (Qty 1)
M4815 Shaft, Drive (Qty 1)
M4816 Shaft, Idle (Qty 1)
24 M4817 Bearing, Rulon (Qty 4)
M4818 Sprocket, Wire Belt (Qty 10)
25 M7495 Pulley, Timing 1/5 P 3/8 Wide Motor
(Sprocket) (Qty 1) (15 Tooth)
26 þ M5425 Pulley, Timing 1/5 P 3/8 Wide Conveyor
(Sprocket) (Qty 1) (30 Tooth)
27 þ M5423 Belt, Timing (Qty 1) (Marked "200XL")
FOR OVENS MANUFACTURED
BEFORE 04/01/96 & UP TO SERIAL
NUMBER 040196GC038S
Ref. Part
No. No. Description
M0200 Knob, Lock Phenolic, Black (Qty 2)
þ M6087 Knob, Low Profile (Qty 1)
M8209 Motor, Gear w/ Encoder Replacement Kit
**See Note
þ M7994 Motor, Gear w/Encoder (Qty 1) Motor only
**See note
NOTE: Part number M8209 is needed only to
convert from old style (M7126-no longer
available). After you've converted this
motor, you will only need to order part
number M7994.
M7995 Cable, Encoder (for Motor M7994)
(with molex connector at each end)
M4954 Control Cover Assy. w/ Access Door (Qty 1)
M6035 Latch, Access Door (Qty 1)
M5424 Pulley, Timing 1/5 P 3/8 Wide (Sprocket)
(Qty 1) (12 Tooth)
.
