Viewing your video
Power your vehicle, and connect the batteries to the transmitter and receiver to
activate your OSD/FPV setup.
We recommend the following devices for displaying the video transmitted by your
3DR Video Kit.
» FPV monitors are a great, portable solution for viewing your video at the field.
Purchase a monitor/receiver compatible with your kit at store.3drobotics.com .
» Turn your computer into a video capturing platform with this AV-USB adapter .
(This solution requires an AV male-to-male adapter.)
Transmitter specifications
» 5.8 GHz 200 mW wireless AV transmitter:
» Transmitter frequency / channel amount: 5705-5945 MHz / 8 CH
» Output power: 200 mW/33 dBm
» Frequency control: Built-in frequency & phase lock loop
» AV input: analog AV signal input
» ANT connector: RP-SMA
» Power supply: DC 7-12 volts
» Current supply: 850 mA
» Size: 68*26*28 mm
» Weight: 60 g (including antenna)
» Gross weight: 85 g
» 5.8GHz Wireless AV Receiver:
» Receiving Frequency:5705-5945MHz / 8CH
» Receiving Sensitivity:-90dBm
» Antenna connector: RP-SMA
» Power supply voltage:DC 7-12V
» Supply current: 150mA
» Dimension: 61*52*13mm
Receiver specifications
