Zero Gravity Honda VFR 1200F (2010 and up) Windscreen - Manual (Page 2)

Fig 5. Overview of Windscreen and finish plate re-
moving locations.
Note: The finish plate is attached to the stock
windscreen by two phillips screws.
Honda VFR 1200F 2010 - 2013 DIY Windscreen Install
2
455 install
SPORTBIKE SADDLES & WINDSCREENS
WWW.ZEROGRAVITY-RACING.COM
FIG4
FIG6
FIG5
Slide
down
Fig 6. Now you are ready to unlock the screen from
the fairing. Apply light pressure from the top
of the back side of the finish plate . There are
three retention locations on top to dislodge and also
one located at the very bottom of the finish plate.
Apply light pressure separating the clip from the fair-
ing, and slide the windscreen/finish plate down.
Note: The finish plate is attached to the stock
windscreen.
Fig 4. Locate the upper fairing, Lift windscreen away
from the mirror mounting standoffs. It should look like
this on both sides of the windscreen.
Lift Windscreen away from
the Mirror mounting location
FIG7
Finish Plate
Clips &
Retention
Male Location
Finish Plate Clips
& Retention
Female Location
Remove
Fig 7. Now you are ready to separate the finish plate
from the stock windscreen. Locate the two Phillips
screws and remove.
Remove
Remove
