Zero Gravity BMW S1000RR Windscreen - Manual

1
810 install
Rev.a
FIG1
Fig 2. Remove all 8 fastener screws.
Fig 3. HERE IS THE TRICKY PART! You have to
carefully recline the windscreen down from the fairing.
It will be pivoting in two places one on each side.
(See FIG3A).
Helpful hints: Use metric tools, clean hands, put the bike on a stand. Do not pry on the screen excessively, as it can break
without much warning.
B BM MW W S S1 10 00 00 0R RR R D DIIYY W Wiinnddssccrreeeenn IInnssttaallll
SPORTBIKE SADDLES & WINDSCREENS
WWW.ZEROGRAVITY-RACING.COM
Installation Instructions for BMW S1000RR
Thank you for purchasing one of Zero Gravity’s windscreens which has been designed and manufactured to give
years of safe and fun riding. This instruction manual gives you an in-depth look at the installation process.
To receive
further assistance or parts please e-mail [email protected].
PLEASE READ BEFORE MOUNTING YOUR WINDSCREEN
FIG2
FIG3
Fig 3A. This photo shows he pivoting points on either
side of the screen. Be careful not to over pivot!
FIG3A
Pivoting
point
Pivoting
point
Push
Down
Lift Up
Fig 1. Remove both mirrors. The fasteners are behind
the fairing. Be careful not to drop the mirrors!
Pivot
Pivot
