Yamato Scientific IQ820 Low Temperature Incubators - Manual (Page 44)

41
Replacement Parts Table
Symbol Part Name Specification M anufacturer Code No.
X1, 2, 3, 6, 7, 8 Relay AP3124K Matsushita A0334
X4, 5 Relay G3R-1-T DC6V OMRON 2-05-000-0026
P1, 2 Terminal block MO11-0FX 15P Toyo Giken LT00001083
FM1, 2 Fan UF12A10BTH Yamato Scientific 2-15-000-0010
SSR SSR YLT-SSR-01 Yamato Scientific 2-16-000-0035
TF Transformer AC200V Yamato Scientific 2-18-000-0044
TH1, 2
Temperature
sensor
Pt100Ω/K-Thermocouple Yamato Scientific LT00001081
ELB
Earth leakage
breaker
FG32R/15-30MA Fuji Denki 2-06-005-0003
Solenoid valve SEV-502DXF Saginomiya 3-02-006-0003
Solenoid valve NEV-603DXF Saginomiya 3-02-006-0004
RF1, 2 Compressor C-2SN250L0U SANYO 3-01-006-0003
Condenser 1-000-0005-07-0 SANYO 3-01-006-0007
FM2, 4 Fan motor SE4-C041NP SANYO 3-01-006-0006
Dryer KC-10432 Meiko Kiki 3-20-003-6002
Charge valve FV222D0010C Meiko Kiki 3-25-001-0002
Accumulator SAC-154000 SANYO 3-23-000-0001
H1, 3 Heater 550W/100V Yamato Scientific IN161
H2, 4 Cord heater 19W/100V Yamato Scientific IB016
Evaporator Yamato Scientific IN600-30310
Capillary φ1.0×3000mm Yamato Scientific IN800-30121
CONT1, 2 PLANAR board VS4 Yamato Scientific 1-02-000-0053
PIO1, 2
Display circuit
board
VS4 Yamato Scientific 1-02-000-0051
DFF
Defrost circuit
board
IQ820 Yamato Scientific LT00001082
