Description and Function of Each Part
Defrost Control Panel
MANUAL
DEFROST
ON
CYCLE
DEFROST
ON
OFF
UPPER MANUAL
DEFROST
ON
CYCLE
DEFROST
ON
OFF
LOWER
No. Name Function
① Manual Defrost Key (Upper Stage) Uses this key for activating the manual defrost function of
the upper stage.
② Cycle Defrost Key (Upper Stage)
Uses this key for activating the cycle defrost function of the
upper stage.
③ Manual Defrost Lamp (Upper Stage)
Lights this lamp during performing the manual defrost
function of the upper stage.
④ Cycle Defrost Lamp (Upper Stage)
Lights this lamp in the following status:
-
The cycle defrost function of the upper stage is under
operation during the defrost operation.
- The cycle defrost function is under operation with the
defrost stopped.
⑤ Manual Defrost Key (Lower Stage)
Uses this key for activating the manual defr ost function of
the upper stage.
⑥ Cycle Defrost Key (Lower Stage)
Uses this key for activating the cycle defrost function of the
upper stage.
⑦ Manual Defrost Lamp (Lower Stage)
Lights this lamp during performing the manual defrost
function of the upper stage.
⑧ Cycle Defrost Lamp (Lower Stage) Lights this lamp in the following status:
-
The cycle defrost function of the upper stage is under
operation during the defrost operation.
- The cycle defrost function is under operation with the
defrost stopped.
⑧ ③
① ② ⑤ ⑥
⑦ ④
