Page 12
Introduction
8
Bottom view
Connector panel
Lamp door
Rear adjuster
Rear adjuster
Front adjuster
Front adjuster
RGB signal input
(PC/ YPbPr/ YCbCr)
USB connector
RGB
signal output
S-Video jack
Audio/ Video
connector
PC Audio jack
DVI-I connector
RS 232 control port
For external control
systems and used by
service personnel.
