Wood’s Powr-Grip LB6ALO - Manual (Page 6)

Rev 0.0/4-10 4 LB6ALO: #35202AFT
A
DAPTING THE
L
IFT
B
AR
1) Remove the 2 bolts with nuts that secure the upper lift bar segment, and remove it from the
lower lift bar segment (see previous illustration).
2) Install the upper lift bar segment of different length and/or reverse the lift bail orientation, as
necessary for the intended application (see preceding discussion).
3) Align the bolt holes in the upper segment and the lower segment, and reinstall the bolts.
4) After the bolts are tightened securely, continue assembling the vacuum lifter as directed in
the ASSEMBLY section of the lifter's instruction manual.
OPERATION
After the Adaptable Length Lift Bar has been installed and configured to optimize the function of
the vacuum lifter for its intended use, operate the lifter as directed in the OPERATION section of
lifter's instruction manual.
MAINTENANCE
When performing inspections and tests as directed in the instruction manual for the vacuum
lifter, be sure to include all parts of the Adaptable Length Lift Bar whenever applicable.
REPLACEMENT PARTS LIST
Stock No. Description Qty.
54214 Foam Washer 1
13200 3/32" x 1" Cotter Pin 1
12756 3/8" Lock Washer 2
11120 3/8-16 Hex Nut 2
10814 3/8-16 x 3-3/4" Hex Head Bolt - Grade 5 2
SERVICE ONLY WITH IDENTICAL REPLACEMENT PARTS
SUPPLIED BY OR APPROVED BY WOOD'S POWR-GRIP CO., INC.
