Rev 0.0/4-10 1 LB6ALO: #35202AFT
SPECIFICATIONS
Model Number: LB6ALO
Description: This lift bar is designed for applications requiring increased horizontal
reach at the hook point or applications involving minimal clearance
between the lifter and the hoisting equipment, such as installations under
eaves or similar handling situations.
Max. Load Capacity: 700 lbs [320 kg] with standard configuration (A)
650 lbs [295 kg] with shortened configuration (C)
600 lbs [270 kg] with reversed bail configuration (B)
500 lbs [225 kg] with shortened, reversed bail configuration (D)
Weight Increase: 25 lbs [12 kg]
Note: Make sure to add the weight of all options to the Lifter Weight
when you are selecting appropriate hoisting equipment (see ASSEMBLY in
lifter's instruction manual).
Overhead Clearance Reduction: 11-3/4" [298 mm] with shortened configurations (C or D)
Horizontal Reach Increase: 7-5/8" [193 mm] with reversed bail configurations (B or D)
WARNINGS
Powr-Grip is pleased to offer the most reliable materials handling products available.
Despite the high degree of security provided by the Adaptable Length Lift Bar, certain
precautions must be observed to protect the lifter operator and others.
Never use an Adaptable Length Lift Bar that is damaged, malfunctioning, or missing parts.
Never exceed the Maximum Load Capacity listed for the Adaptable Length Lift Bar (see
SPECIFICATIONS).
Always install the Adaptable Length Lift Bar in the prescribed orientation (see ASSEMBLY:
I
NSTALLATION
).
Always remember that modifications to the Adaptable Length Lift Bar may compromise its
safety. Wood's Powr-Grip cannot be responsible for the safety of an Adaptable Length Lift
Bar that has been modified by the customer. For consultation, contact Wood's Powr-Grip (see
LIMITED WARRANTY).
