Appendix

11

Hardware Replacement Procedures
WD Sentinel RX4100 Administrator Reference Sheet

Hardware Replacement Procedures

Before You Begin
Installing the WD Sentinel Bezel
Replacing a Hard Drive
Removing the Unit Cover
Replacing the Internal Power Supply
Replacing a Server Fan
Replacing the Riser Card
Replacing the Mid-plane Card

This chapter provides the steps necessary to replace the following components designed for
replacement for the WD Sentinel RX4100.

Hard Drive

Power Supply

Fans

Riser

Midplane

The WD Sentinel is also designed to be easily mounted on a rack.

Before You Begin

Ensure that you have the correct replacement unit.

Review the procedures before beginning to replace a part.
