16 17
Convertisseur de signaux DC/DC CCC HF
avec séparation 3 voies
de la WAVESERIES
Type N° de réf.
Raccord à visser
WAS5 CCC HF 0 ... 20 mA/0 ... 20 mA
8447160000
WAS5 CCC HF 0 ... 20 mA/4 ... 20 mA 8447190000
WAS5 CVC HF 0 ... 20 mA/0 ... 10 V 8447220000
WAS5 CCC HF 4 ... 20 V/0 ... 20 mA 8447250000
WAS5 CVC HF 4 ... 20 mA/0 ... 10 V 8447280000
WAS5 VCC HF 0 ... 10 V/0 ... 20 mA 8447310000
WAS5 VCC HF 0 ... 10 V/4 ... 20 mA 8447340000
WAS5 VVC HF 0 ... 10 V/0 ... 10 V 8447370000
WAS5 VVC HF - 10 ... + 10 V/- 10 ...+ 10 V 8561610000
Raccord à ressort de traction
WAZ5 CCC HF 0 ... 20 mA/0 ... 20 mA
8447170000
WAZ5 CCC HF 0 ... 20 mA/4 ... 20 mA 8447200000
WAZ5 CVC HF 0 ... 20 mA/0 ... 10 V 8447230000
WAZ5 CCC HF 4 ... 20 mA/0 ... 20 mA 8447260000
WAZ5 CVC HF 4 ... 20 mA/0 ... 10 V 8447290000
WAZ5 VCC HF 0 ... 10 V/0 ... 20 mA 8447320000
WAZ5 VCC HF 0 ... 10 V/4 ... 20 mA 8447350000
WAZ5 VVC HF 0 ... 10 V/0 ... 10 V 8447380000
WAZ5 VVC HF - 10 ... + 10 V/- 10 ...+ 10 V 8587000000
Lisez cette notice d'utilisation avant d'installer le produit et gardez cette brochure pour
obtenir des informations additionnelles.
8 Accessories
Cross-connection ZQV 2,5N/2 red 1717900000
Cross-connection ZQV 2,5N/2 blue 1717990000
Cross-connection ZQV 2,5N/2 yellow 1693800000
Terminal connector, 3-pole for screw-type connection
BLZ 5.08/3 SN OR
- orange
1526560000
- black 1526510000
Terminal connector, 3-pole for tension clamp connection
BLZF 5.08/3
- orange
1707470000
- black 1707700000
Connector markers
WS 10/5 Multicard for plotter labelling
1635010000
WS 10/5 blank 1060860000
WS 10/5 blank 1060860000
In the interest of protecting the environment, return any spare
operating instructions to your local stockist for re-use.
Printed on chlorine-free bleached paper.
