Weidmuller WAVE Analog PRO RTD - Manual (Page 7)

20
Selecting the measuring range
SW2
T R Poti 1 2 3 4 5
40K 20
Ω
20% 1 1 1 1 1
50K 25
Ω
25% 1 1 1 1 0
60K 30
Ω
30% 1 1 1 0 1
70K 35
Ω
35% 1 1 1 0 0
80K 40
Ω
40% 1 1 0 1 1
90K 45
Ω
45% 1 1 0 1 0
100K 50
Ω
50% 1 1 0 0 1
110K 55
Ω
55% 1 1 0 0 0
120K 60
Ω
60% 1 0 1 1 1
125K 62,5
Ω
62,5% 1 0 1 1 0
130K 65
Ω
65% 1 0 1 0 1
140K 70
Ω
70% 1 0 1 0 0
150K 75
Ω
75% 1 0 0 1 1
160K 80
Ω
80% 1 0 0 1 0
170K 85
Ω
85% 1 0 0 0 1
180K 90
Ω
90% 1 0 0 0 0
190K 95
Ω
95% 0 1 1 1 1
200K 100
Ω
100% 0 1 1 1 0
250K 125
Ω
– 0 1 1 0 1
300K 150
Ω
– 0 1 1 0 0
350K 175
Ω
– 0 1 0 1 1
400K 200
Ω
– 0 1 0 1 0
450K 225
Ω
– 0 1 0 0 1
500K 250
Ω
– 0 1 0 0 0
550K 275
Ω
– 0 0 1 1 1
