3.5 Setting examples
1. . Input –150 mV to +150 mV, output –20 mA to +20 mA
2. . Input +10 mV to +165 mV, output 0 mA to +20 mA
a. Switch on input range 0 to ±150 mV, activate Span potentiometer.
Switch on output range 0 to ±20 mA and offset 0 %
Input S1 S2
Input range 1 2 3 4 1 2 3
0 to ±150 mV ON
Switch S2 4
Span potentiometer: input range x 0.3 to x 3.33
Output S1 S3
Output range 5 6 7 1 2
0 to ±20 mA ON
Offset
(in % of output span) S1 S2
8 9 10 5
0 % ON
Input S1 S2
Input range 1 2 3 4 1 2 3 4
0 to ±150 mV ON ON
Output S1 S3
Output range 5 6 7 1 2
0 to ±20 mA ON
Offset
(in % of output span) S1 S2
8 9 10 5
+ 0 % ON
