2-2 Introduction MN1940
A “Baldor Motion Toolkit CD” is available. This contains the Baldor SPI Interface software,
used for communicating and configuring the DSM.
This manual is intended to guide you through the installation of the DSM. The chapters should
be read in sequence.
The Basic Installation section describes the mechanical installation of the DSM.
The following sections require knowledge of the low level input/output requirements of the
device that will control the DSM, and an understanding of computer software installation. If you
are not qualified in these areas you should seek assistance before proceeding.
Note: You can check that you have the latest releases by visiting the website
www.baldormotion.com/supportme.
2.1.1 Option availability
Model ‘F’
flying leads
‘P’
connector
‘M’
control knob flying leads
option
connector
option
control knob
option
DSMS
17
Yes
All models
Yes
All
models
Yes
All
models
DSMS
23
Yes
All models
Yes
All
models
Yes
All
models
DSMS
34
Yes
All models
No Yes
All
models
