15.PHILLIPS SCREW 1 1/8"
29. GLASS SUPPORT
MODEL VG06042
3
30. STRUCTURAL ARM
2. TURNING HINGE
BASE MIRRORED 4. TURNING HINGE
MIRRORED
5. FRONT FIXED PANEL
6. DOOR 7. SIDE SEAL STRIP - 73" 8. HANDLE ASSEMBLY 9. SIDE SEAL STRIP
W/OUT BUMP - 73"
10. DOOR BOTTOM SEAL
STRIP - 36"
14. PHILLIPS SCREW 1 5/8" 13. HEX SCREW 1 5/8" 12. DOOR SIDE SEAL
STRIP - 73"
11. DOOR THRESHOLD -
36"
16. PLASTIC ANCHORS -
GREEN
17. PLASTIC ANCHORS -
WHITE
18. SIDE PANEL 19. DOOR MAGNETIC SEAL
STRIP - 73"
20. SHELF GLASS
21. SHELF GLASS
HOLDER (TO WALL)
22. SHELF GLASS
HOLDER (TO GLASS)
96001
24. SCREW COVER
96013
98037 98038 96011
25. RIGHT THRESHOLD
CLIP W/SCREW H0LE
26. LEFT THRESHOLD
CLIP W/SCREW H0LE 27. RIGHT THRESHOLD
END CUP 28. LEFT THRESHOLD
END CUP
1. TURNING HINGE
BASE 3. TURNING HINGE
* 23. F-SHAPED SEAL
STRIP - 73"
* PART USED IN REPLACEMENT OF #19 (MAGNETIC
SEAL STRIPS) ONLY WHEN PART #18 (SIDE PANEL) IS
NOT INSTALLED. THIS IS AN OPTION THE VG06042
MODEL OFFERS.
TYPE A TYPE B TYPE C
98041 98042 98043 98044 97023
97024-28
97024-34 98045 96014
98046 98047 98039 98035
97025-12
97025-24 97026
98055 98056 96015
98048 98049 98050
98057
98058 98051 98052 98053
98054
96004
oval cap
