pg. 9
657070
2. Install column joint end onto stock steering shaft and tighten allen style screw to hold joint in place.
Make sure the end of the shaft is lined up with the end of the yoke on the u-joint so that it is in as far
as possible without protruding into the middle.
3. Rotate the column shaft joint to access the thru-hole.
4. Use supplied drill bit to drill through column shaft and blank side of u-joint. Start to install the larger
roll pin provided by tapping it into the hole. Next tap the smaller pin into the larger pin already started
until both pins are flush with the outside of the u-joint. This will ensure a positive lock.
5. Remove the allen set screw and apply “RED” locktite thread lock to threads and reinstall & tighten.
Shaft is
even with
inside edge
of u-joint.
