BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
1-30F-3
MAY, 2011
CONTROL VALVE AND PLUMBING KIT 2-5976
CASE IH 1120 and Cub Cadet 7000, 7200, 7205 HST, 7192, 7194 & 7195
REF.
PART
DESCRIPTION
QTY.
NO.
NO.
REQ’D.
1
38411
Valve, Dukes P/N 1627-Ft
1
2
38903
Linkage-Bracket
1
3
38911-1
Flt Soc. Scrw 5/16-24 X 3/4
1
4
38910-2
Socket Hd Capscrew 5/16-24 X 0.75
1
5
38908
Handle Assy Zp
1
6
26009-3
Rod End 1/4-28 Ydp
2
7
38900-5
Rod End,Ball Joint 1/4-28 Ydp
1
8
38904-1
Stud (Rod End) Ydp
1
9
38910-1
Soc Hd Capscrew 1/4-28 X 0.75
3
10
-------
Flatwasher 1/4 Sae
3
11
-------
Lockwasher 1/4
2
12
-------
Nut Hex 1/4-28 Zc
2
13
-------
Lock Nut 1/4-28
1
14
36584
Fitting, Power Beyound
1
15
32845-1
Adp Hyd Elbow 6mj - 6mb90 Ydp
1
16
38928-1
Hose 3/8 X 6.88 Lg
1
17
38928-2
Hose 3/8 X 7.88 Lg
1
18
38928-3
Hose 3/8 X 8.50 Lg
1
19
38928-4
Hose 3/8 X 13.00 Lg
1
20
36387-5+
Hose 3/8 X 44" (Sae100r1)
2
21
38163-2
Hose 3/8 X 44" (Sae100r1)
1
22
38912
Spacer, Black
4
23
38926
Valve Box Assembly
1
24
38927
Cover
1
25
-------
Capscrew, 1/4-20x2 G5 Zc
2
26
-------
Nut Hex Lock Type N 1/4-20
2
27
38440-1
J" Clip
2
28
-------
Screw #10-16 X 1/2 Typ Ab,Pan Hd
2
29
6147-4
Coupler Body-Female
4
30
36240-10
Spiral Band,Plastic-Red- 1" Id
1
36240-11
Spiral Band,Plastic-Yel-1" Id
1
36240-12
Spiral Band,Plastic-Green-1"Id
1
36240-9
Spiral Band,Plastic-Blue-1" Id
1
31
38653
Boot-Black (Dukes#1680-125)
1
32
38930-1
Cap Nut (Arden#C60002-218)
1
33
38902
Ball-Handle (Davies #35k)
1
34
38981
Tube, Valve Mount
1
35
-------
Capscrew, 1/2-13 X 2-1/2
2
36
-------
Flatwasher, 1/2
2
37
-------
Locknut 1/2-13
5
38
-------
Capscrew 3/8-16 X 2-1/4
2
39
-------
Locknut 3/8-16
2
40
38929
Decal, Single Handle Control
1
41
25945-1
Fitting 3/8-19t Iso To 3/8-18
3
42
6006-6
Adaptor, Elbow, 3/8x3/8
3
43
8137-1
Strap-Adjust .19 X 11.00 B
4
44
7438-1
Tarp Strap 22" Reach
1
45
34853-11
Nylon Sleeve (1.59 Id X 66")
1
46
6137-4
Coupling Body-Male Ydp
4
47
36240-5
Spiral Band,Plastic-Blue .62id
1
36240-6
Spiral Band-Plast-Red-.62 I.D.
1
36240-7
Spiral Band-Plast-Yel-.62 .I.D
1
36240-8
Spiral Band-Plast-Grn-.62 .I..
1
48
36251-3
Hose, 1/4 X 60 Long
4
