Shop layout – Therma-Tru SHOP 2 Equipment and Facilities - Book Size User Manual
Page 8
Equipment
and Facilities
2.8
2014 (BOOK SIZE)
Shop 2
Shop Layout
Recommended door unit assembly area for a
“U” shaped assembly line.
110 v Suppl
y
220 v (3 Phase)
Air (90-95 PSI)
Compressor
Template
Rack
Door Lite Cutout
Miter Saw
Frame Prep. T
able
Table Saw
Door Prep. Table
Component
s
In
Assembled Units
Out
Door Prep. Parts
Racks
Frame Parts
Racks
(Jamb legs vertical)
Frame T
able
Misc. Door Prep. Parts
24’
36’
