Shop layout – Therma-Tru SHOP 2 Equipment and Facilities - Book Size User Manual
Page 7
Equipment
and Facilities
Shop 2
2014 (BOOK SIZE)
2.7
Shop Layout
Compressor
Overhead
Door
Template
Rack
Door Lite Cutout
Drill Press (optional)
Frame Parts
Racks
(Jamb legs vertical)
Miter Saw
Hand T
ool
Storage
Frame Prep.
Table
Table Saw
Door Prep.
Table
Door Prep. Parts
Racks
Component
s
In
Assembled Units
Out
110 v Suppl
y
220 v (3 Phase)
Air (90-95 PSI)
35’
40’
Recommended door unit assembly area for an
“L” shaped assembly line.
