Equipment
and Facilities

2.4

2014 (BOOK SIZE)

Shop 2

Equipment

1-1/2”

1-1/2”

4-1/2”

1-1/2”

41-1/8”

36-5/8”

10”

21-1/8”

1-1/2” sq. x 70-1/8” long (3 reqd)

Butt frame head to this block.

3” x 4” hole for security plate clearance (3 reqd)

NOTE: For longer wear- plastic laminate can be added to 3/4” plywood top.

44-7/8”

8”

35-1/2”

1-1/2”

2 x 4 Construction

3/4” Plywood 79” x 35-1/8”

70-1/8”

85”

88”

DET

AIL

B

DET

AIL

B

SECTION A-A

A

A

3-1/2”

8-7/8”

DOOR FRAME

ASSEMBL

Y T

ABLE
