Page 10
Smooth-Star
Door Panel
Dimensions
5.10
2014 (U1 REVISED)
Comp 5
6/8 Smooth-Star Doors
A
B
23-27/32”
C
9-1/8”
4-7/8”
4-1/8”
7-7/8”
4-21/32”
25”
21-13/16”
9-3/8”
79-3/64”
A
B
9-7/8”
D
C
E
F
4-3/16”
7-7/8”
4-19/32”
25”
6-3/16”
21-13/16”
9-25/64”
79-3/64”
Size
A
B
C
2/8 31-13/16” 4-1/16”
4-11/32”
2/10 33-13/16” 5-1/16”
5-11/32”
3/0 35-13/16” 6-1/16”
6-11/32”
Size
A
B
C
D
E
F
2/6N 29-13/16”
3-7/8”
4-13/32”
2-11/32”
2/6
29-13/16” 2-31/32”
3-11/32”
4-1/8”
2/8
31-13/16” 3-31/32”
4-11/32”
4-1/8”
2/10 33-13/16” 4-31/32”
5-11/32”
4-1/8”
3/0
35-13/16” 5-31/32”
6-11/32”
4-1/8”
2 Lite 4 Panel
(296, 996, 0806)
(Slab-SS060U1)
4 Lite 4 Panel
(444)
(Slab-SS060U1)
23-1/8”
23-1/8”
3-3/8”
8-13/16”
9-1/8”
9-1/8”
9-1/8”
9-1/8”
4-7/8”
4-7/8”
4-7/8”
4-7/8”
Daylight Opening: 21-1/8" x 5"
(93 sq.in.)
A
B
9 15/16"
D
4 5/32"
7 15/16"
4 19/32"
25"
21 13/16"
9 3/8"
79-3/64"
2 Lite 4 Panel
(Glass - 296, 996, 0806)
(Slab - SS060U1)
C
E
F
Size
A
B
C
D
E
F
*2/6N
29-13/16" 3-27/32" 4-13/32" 2-9/32" 8-13/16" 19-29/32"
2/6
29-13/16" 2-15/16" 3-5/16"
4-1/8"
9-1/8"
23-5/32"
2/8
31-13/16" 3-15/16" 4-5/16"
4-1/8"
9-1/8"
23-5/32"
2/10
33-13/16" 4-15/16" 5-5/16"
4-1/8"
9-1/8"
23-5/32"
3/0
35-13/16" 5-15/16" 6-5/16"
4-1/8"
9-1/8"
23-5/32"
*Impact slab not available.
Daylight Opening: 6-15/16" x 4-15/16" (per lite)
(Total 68 sq.in.)
