Therma-Tru Doors Repair and Replacement - Manual (Page 29)

Repair and
Replacement
SITE 5 2014 5.29
Storm Door Strip Application
(Continuous Sill)
Make Storm Door Adapter Strips
4-9/16” Jamb Adapter
1-15/32” 1-1/16”
6°
80-21/32”
1-15/32”
1”
6°
80-1/16”
1-15/32” 1-1/16”
6°
80-7/8”
1-15/32”
3”
6°
80-1/4”
Use standard mull casings
(Part No. MSMLCAS).
Cut to length as shown,
and bevel one end to make
base and face adapter
strips.
One set (2 pieces - face
and base adapter) is used
at each mullion.
Face Adapter Strip Base Adapter Strip
Face Adapter Strip Base Adapter Strip
6-9/16” Jamb Adapter
Purchase or fabricate
a base adaptor strip as
shown (Part number
MSSDADP).
Use one standard
mull casing (Part No.
MSMLCAS). Cut to
length as shown, and
bevel one end to make
a face adapter strip.
One set (2 pieces -
face and base adapter)
is used at each mullion.
